Standards

       IEC 60317-0-1:2014

Insulation Coatings  : Polyester imide 200

Dimensions               : 0.05mm to 2.50mm

Applications

      Suitable for automated soldering equipment used for

     production/manufacturing of small motors, transformers,

     relays and magnet coils.

    Mechanical Properties (For 0.3mm)

Elongation                         : >30%

Springiness                      :<50

Adherence – Flexibility:    Excellent

Resistance to Abrasion :    >67.75N

Electrical Properties

Breakdown Voltage:          7kV

Thermal Properties

Temperature Index:           200

Cut through:                     ≥ 225 ℃

Heat Shock:                       ≥360 ℃

Chemical Properties

Solvent Test:                 4H

Solderability:                390°

Resistance to Refrigerants : -

Bare Conductor – Copper Characteristics (Annealed Condition)

Electrical Resistivity @ 20°C 0.017241Ωmm²/m Temperature Coefficient @ 20°C : 0.00694°C Specific Weight : 8.89 Gr/cm³ Ultimate Tensile Strength : 22-30 kg/mm²

Primary Insulation Colour : Transparent / Natural
